ARGO - HYTOS: New 4/3 electromagnetically controlled built-in slide valve

The manufacturer of hydraulic components presents a new valve switchboard controlled by two electromagnets.
Valve connection thread ¾-16 UNF-2A (standard chamber A4 (C-8-4)).

SD2E-A4 / H3 *

Product novelty no. 01-2022 / NEW 4/3 electromagnetically operated built-in slide valve (cleverreach.com)

Product benefits:

  • High hydraulic power in a compact design
  • Flow rate up to 30 l / min (7.9 GPM), working pressure up to 350 bar (5,080 PSI)
  • Ports 2, 3, 4 can be loaded at 350 bar (5,080 PSI), port 1 at 250 bar (3,630 PSI)
  • Low pressure losses
  • 2 types of valves
  • C19B * coil interchangeable within the SD * -A * / H * product line
  • Emergency control with locking in both extreme positions without the need for tools
  • High level of surface protection by galvanizing according to ISO 9227 (resistance 520 h)
  • Lifetime guaranteed up to 10 million cycles

Technical parameters:

  • Volume flow up to 30 l / min (7.9 GPM), operating pressure up to 350 bar (5080 PSI)
  • UNF Standardized Chamber 3 / 4-16 (C-8-4)
  • HNBR seal (fluid operating temperature range -30… + 80 ° C, -22 ... +176 ° F)
  • FPM optional seal (fluid operating temperature range -20… + 80 ° C, -4 ... +176 ° F)
